Name: Roadway Block

Display Field: ROUTENAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: For a city, street blocks are a very common way in which to organize and relate work (e.g. 'I need to fix a pothole on the 1600 Block of Pennsylvania Ave'). Although driveways or alleys may intersect streets, this representation requires that the segment remain unbroken. Road types include streets. Previously Called Street Segments. Note that there are no from/to address fields. We will not be maintaining them in our data. There also will be no generating a 'streetname' list.For more information please visit DDOT's wiki page at https://wiki.ddot.dc.gov/display/public/GIS/Roadway+Characteristics

Copyright Text: DC District Department of Transportation

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584595.84228207
YMin: 4692088.917829138
XMax: -8561515.62835993
YMax: 4720993.064900679
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 130, 54, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ROUTEID ( type: esriFieldTypeString, alias: Route ID for roadway, length: 255 )
• FROMMEASURE ( type: esriFieldTypeDouble, alias: From Measure (m) )
• TOMEASURE ( type: esriFieldTypeDouble, alias: To Measure (m) )
• ROUTENAME ( type: esriFieldTypeString, alias: Route Name, length: 255 )
• ROADTYPE ( type: esriFieldTypeString, alias: RoadType, length: 255 , Coded Values: [1: Street] , [2: Service Road] , [3: Ramp] , ...5 more... )
• BLOCKKEY ( type: esriFieldTypeString, alias: BlockKey, length: 255 )
• TOTALTRAVELLANES ( type: esriFieldTypeSmallInteger, alias: Total # Travel Lanes )
• TOTALPARKINGLANES ( type: esriFieldTypeSmallInteger, alias: Total # Parking Lanes )
• TOTALRAISEDBUFFERS ( type: esriFieldTypeSmallInteger, alias: Total # Raised Buffers )
• TOTALTRAVELLANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Travel Lanes )
• TOTALCROSSSECTIONWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of All Cross-sections )
• TOTALPARKINGLANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Parking Lanes )
• TOTALRAISEDBUFFERWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Buffer/Barriers )
• TOTALTRAVELLANESINBOUND ( type: esriFieldTypeSmallInteger, alias: TotalInbound Travel Lanes )
• TOTALTRAVELLANESOUTBOUND ( type: esriFieldTypeSmallInteger, alias: TotalOutbound Travel Lanes )
• TOTALTRAVELLANESBIDIRECTIONAL ( type: esriFieldTypeSmallInteger, alias: Total BiDirectional Travel Lanes )
• TOTALTRAVELLANESREVERSIBLE ( type: esriFieldTypeSmallInteger, alias: Total Reversible Travel Lanes )
• SUMMARYDIRECTION ( type: esriFieldTypeString, alias: General Directionality for Segment, length: 255 , Coded Values: [BD: Bi-directional] , [OB: Oneway in Outbound Direction] , [IB: Oneway in Inbound Direction] )
• BIKELANE_PARKINGLANE_ADJACENT ( type: esriFieldTypeString, alias: Parking Lane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_THROUGHLANE_ADJACENT ( type: esriFieldTypeString, alias: Throughlane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_POCKETLANE_ADJACENT ( type: esriFieldTypeString, alias: Pocket Turnlane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_CONTRAFLOW ( type: esriFieldTypeString, alias: Bikelane is Contraflow, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_CONVENTIONAL ( type: esriFieldTypeString, alias: Conventional Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_DUAL_PROTECTED ( type: esriFieldTypeString, alias: Protected Dual Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_PROTECTED ( type: esriFieldTypeString, alias: Protected Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_BUFFERED ( type: esriFieldTypeString, alias: Buffered Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• DOUBLEYELLOW_LINE ( type: esriFieldTypeString, alias: Double Yellow Line on Segment, length: 255 )
• SECTIONFLAGS ( type: esriFieldTypeString, alias: SectionFlags, length: 255 )
• LOC_ERROR ( type: esriFieldTypeString, alias: LOC_ERROR, length: 50 )
• MIDMEASURE ( type: esriFieldTypeDouble, alias: MIDMEASURE )
• AADT ( type: esriFieldTypeInteger, alias: AADT )
• AADT_YEAR ( type: esriFieldTypeInteger, alias: AADT Year )
• FHWAFUNCTIONALCLASS ( type: esriFieldTypeSmallInteger, alias: FHWA Functional Class , Coded Values: [1: Interstate] , [2: Principal Arterial - Other Freeways or Expressways] , [3: Principal Arterial - Other] , ...4 more... )
• HPMSID ( type: esriFieldTypeString, alias: HPMS Section ID, length: 255 )
• HPMSSECTIONTYPE ( type: esriFieldTypeSmallInteger, alias: HPMS Section Type )
• ID ( type: esriFieldTypeString, alias: Overlay ID, length: 255 )
• IRI ( type: esriFieldTypeInteger, alias: IRI )
• IRI_DATE ( type: esriFieldTypeDate, alias: IRI Date, length: 8 )
• NHSCODE ( type: esriFieldTypeSmallInteger, alias: NHS Code , Coded Values: [0: Not on the NHS] , [1: Is on the NHS] , [2: Major Airport] , ...7 more... )
• OWNERSHIP ( type: esriFieldTypeString, alias: Ownership, length: 255 , Coded Values: [1: DDOT] , [5: Private] , [2: National Park Service] , ...9 more... )
• PCI_CONDCATEGORY ( type: esriFieldTypeString, alias: PCI Condition Category, length: 255 )
• PCI_LASTINSPECTED ( type: esriFieldTypeDate, alias: PCI Last Date Inspected, length: 8 )
• PCI_SCORE ( type: esriFieldTypeDouble, alias: PCI Score )
• QUADRANT ( type: esriFieldTypeSmallInteger, alias: DC Quadrant , Coded Values: [2: NE] , [4: SW] , [0: Unknown] , ...3 more... )
• SIDEWALK_IB_PAVTYPE ( type: esriFieldTypeString, alias: Sidewalk Pavement Type (Inbound), length: 255 )
• SIDEWALK_IB_WIDTH ( type: esriFieldTypeString, alias: Sidewalk Pavement Width (Inbound), length: 255 )
• SIDEWALK_OB_PAVTYPE ( type: esriFieldTypeString, alias: Sidewalk Pavement Type (Outbound), length: 255 )
• SIDEWALK_OB_WIDTH ( type: esriFieldTypeString, alias: Sidewalk Pavement Width (Outbound), length: 255 )
• SPEEDLIMITS_IB ( type: esriFieldTypeInteger, alias: Speed Limit (Inbound) )
• SPEEDLIMITS_IB_ALT ( type: esriFieldTypeInteger, alias: Speed Limit Schools (Inbound) )
• SPEEDLIMITS_OB ( type: esriFieldTypeInteger, alias: Speed Limit (Outbound) )
• SPEEDLIMITS_OB_ALT ( type: esriFieldTypeInteger, alias: Speed Limit Schools (Outbound) )
• STREETNAME ( type: esriFieldTypeString, alias: Street Name, length: 255 )
• STREETTYPE ( type: esriFieldTypeString, alias: Street Type, length: 255 )
• BLOCK_NAME ( type: esriFieldTypeString, alias: MAR Block Name, length: 255 )
• ADDRESS_RANGE_HIGH ( type: esriFieldTypeDouble, alias: Address Range High )
• ADDRESS_RANGE_LOW ( type: esriFieldTypeDouble, alias: Address Range Low )
• ADDRESS_RANGE_RIGHT_HIGH ( type: esriFieldTypeDouble, alias: Address Range Right High )
• ADDRESS_RANGE_LEFT_HIGH ( type: esriFieldTypeDouble, alias: Address Range Left High )
• ADDRESS_RANGE_RIGHT_LOW ( type: esriFieldTypeDouble, alias: Address Range Right Low )
• MAR_ID ( type: esriFieldTypeDouble, alias: MAR Address ID )
• ADDRESS_RANGE_LEFT_LOW ( type: esriFieldTypeDouble, alias: Address Range Left Low )
• BLOCKID ( type: esriFieldTypeString, alias: BlockID, length: 255 )
• DCFUNCTIONALCLASS ( type: esriFieldTypeSmallInteger, alias: DC Functional Class , Coded Values: [11: Interstate] , [12: Other Freeway and Expressway] , [17: Collector] , ...3 more... )
• NHSTYPE ( type: esriFieldTypeString, alias: NHS Type, length: 255 , Coded Values: [NHS Non-Interstate: NHS Non-Interstate] , [NHS Interstate: NHS Interstate] )
• SNOWROUTE_DDOT ( type: esriFieldTypeString, alias: Snow Route DDOT, length: 255 )
• SNOWROUTE_DPW ( type: esriFieldTypeString, alias: Snow Route DPW, length: 255 )
• SNOWSECTION_DDOT ( type: esriFieldTypeString, alias: Snow Section DDOT, length: 255 )
• SNOWZONE_DDOT ( type: esriFieldTypeString, alias: Snow Zone DDOT, length: 255 )
• SNOWZONE_DPW ( type: esriFieldTypeString, alias: Snow Zone DPW, length: 255 )
• LEFTTURN_CURBLANE_EXCL ( type: esriFieldTypeString, alias: Exclusive Left Turn Lane Approaching Int (Oneway only), length: 255 )
• LEFTTURN_CURBLANE_EXCL_LEN ( type: esriFieldTypeSmallInteger, alias: Length Exclusive Left Turn Lane Approaching Int (Ft) )
• RIGHTTURN_CURBLANE_EXCL ( type: esriFieldTypeString, alias: Exclusive Right Turn Lane Approaching Int, length: 255 )
• RIGHTTURN_CURBLANE_EXCL_LEN ( type: esriFieldTypeSmallInteger, alias: Length Exclusive Right Turn Lane Approaching Int (Ft) )
• TOTALBIKELANES ( type: esriFieldTypeSmallInteger, alias: Total Count of Bike Lanes )
• TOTALBIKELANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Total Bike Lane Width )
• RPPDIRECTION ( type: esriFieldTypeString, alias: Resident Parking Permitted (Direction), length: 255 , Coded Values: [1: Outbound (with centerline geometry)] , [2: Inbound (against centerline geometry)] , [3: Bidirectional (both directions allowed)] , ...7 more... )
• RPPSIDE ( type: esriFieldTypeString, alias: Resident Parking Permitted (Side), length: 255 )
• SLOWSTREETINFO ( type: esriFieldTypeString, alias: Is Slow Street?, length: 255 )
• BIKELANE_DUAL_BUFFERED ( type: esriFieldTypeString, alias: Buffered Dual Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• RIGHTTURN_EXCLUSIVE ( type: esriFieldTypeString, alias: Excl Rightturn Lane on Segment, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• LEFTTURN_EXCLUSIVE ( type: esriFieldTypeString, alias: Excl Leftturn Lane on Segment, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BUSLANE_INBOUND ( type: esriFieldTypeString, alias: Bus Lane (Inbound), length: 255 , Coded Values: [L1: Dedicated Bus Lane in the curblane] , [L2: Dedicated Bus Lane in lane adjacent to the curblane (usually a parking lane is the curblane for these cases)] , [L3: Dedicated Bus Lane in both curblane and next lane over.] , ...4 more... )
• BUSLANE_OUTBOUND ( type: esriFieldTypeString, alias: Bus Lane (Outbound), length: 255 , Coded Values: [L1: Dedicated Bus Lane in the curblane] , [L2: Dedicated Bus Lane in lane adjacent to the curblane (usually a parking lane is the curblane for these cases)] , [L3: Dedicated Bus Lane in both curblane and next lane over.] , ...4 more... )
• FROMSTREET ( type: esriFieldTypeString, alias: From Street, length: 500 )
• TOSTREET ( type: esriFieldTypeString, alias: To Street, length: 150 )
• WARD_ID ( type: esriFieldTypeString, alias: Ward, length: 255 )
• ANC_ID ( type: esriFieldTypeString, alias: ANC, length: 255 )
• SMD_ID ( type: esriFieldTypeString, alias: SMD, length: 255 )
• SURFACE_TYPE ( type: esriFieldTypeSmallInteger, alias: Surface Type )
• PARKINGZONE_ROP ( type: esriFieldTypeString, alias: ROP, length: 10 , Coded Values: [1: Outbound (with centerline geometry)] , [2: Inbound (against centerline geometry)] , [3: Bidirectional (both directions allowed)] , ...7 more... )
• PARKINGZONE_RPP ( type: esriFieldTypeString, alias: RPP, length: 10 , Coded Values: [1: Outbound (with centerline geometry)] , [2: Inbound (against centerline geometry)] , [3: Bidirectional (both directions allowed)] , ...7 more... )
• AADT_COMBINATION ( type: esriFieldTypeInteger, alias: AADT_COMBINATION )
• AADT_COMBINATION_YEAR ( type: esriFieldTypeInteger, alias: AADT_COMBINATION_YEAR )
• AADT_SINGLE_UNIT ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT )
• AADT_SINGLE_UNIT_YEAR ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT_YEAR )
• SPEEDHUMP_PRESENT ( type: esriFieldTypeString, alias: SPEEDHUMP_PRESENT, length: 50 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• DC_MAINTENANCE_OPERATIONS ( type: esriFieldTypeString, alias: DC_MAINTENANCE_OPERATIONS, length: 255 , Coded Values: [1: DDOT] , [5: Private] , [2: National Park Service] , ...9 more... )
• MAINTENANCE_OPERATIONS ( type: esriFieldTypeInteger, alias: MAINTENANCE_OPERATIONS )
