Name: Roadway Blockface

Display Field: ROUTEID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Blockface Segments are unbroken sections of the curb. A blockface can be made up of several subblocks, or just one subblock. There are blockfaces on both sides of the road, each dependent on an unbroken length of curb. For more information please visit https://wiki.ddot.dc.gov/display/public/GIS/Roadway+Characteristics.

Copyright Text: District Department of Transportations (DDOT)

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584598.75642658
YMin: 4692085.0554843
XMax: -8561511.797787996
YMax: 4720996.867279754
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 19, 140, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ROUTEID ( type: esriFieldTypeString, alias: Unique identifier of the route that this blockface is on, length: 500 )
• SIDE ( type: esriFieldTypeString, alias: Which side of the route is this blockface on, when looking in digitizing direction, length: 255 )
• MEAS_FROM ( type: esriFieldTypeDouble, alias: measure along the route does this blockface begin )
• MEAS_TO ( type: esriFieldTypeDouble, alias: measure along the route does this blockface end )
• BLOCKFACEKEY ( type: esriFieldTypeString, alias: Unique identifier for each blockface, length: 500 )
• OFFSET ( type: esriFieldTypeSmallInteger, alias: Offset value to be able to visualize the blockfaces on a map )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
