Name: Roadway SubBlock

Display Field: ROUTENAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: SubBlock represent the near-full extent of our centerline network (only driveways are excluded). SubBlock is the finest grained, 'base' segments from which all other segmentation patterns can be constructed (including Blocks). SubBlock is the original source features for our DDOT Street Centerlines data. Road types include streets, Alleys, Ramps, Service Roads, and Trails. Previously called Roadway Segments. For more information please visit DDOT's wiki page at https://wiki.ddot.dc.gov/display/public/GIS/Roadway+Characteristics

Copyright Text: DC District Department of Transportation

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584595.84228207
YMin: 4692088.917829138
XMax: -8561515.62835993
YMax: 4720993.064900679
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [86, 0, 133, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ROUTEID ( type: esriFieldTypeString, alias: Route ID for roadway, length: 255 )
• FROMMEASURE ( type: esriFieldTypeDouble, alias: From Measure (m) )
• TOMEASURE ( type: esriFieldTypeDouble, alias: To Measure (m) )
• ROUTENAME ( type: esriFieldTypeString, alias: Route Name, length: 255 )
• ROADTYPE ( type: esriFieldTypeString, alias: Road Type, length: 255 , Coded Values: [1: Street] , [2: Service Road] , [3: Ramp] , ...5 more... )
• SUBBLOCKKEY ( type: esriFieldTypeString, alias: SubBlockKey, length: 255 )
• TOTALTRAVELLANES ( type: esriFieldTypeSmallInteger, alias: Total # Travel Lanes )
• TOTALPARKINGLANES ( type: esriFieldTypeSmallInteger, alias: Total # Parking Lanes )
• TOTALRAISEDBUFFERS ( type: esriFieldTypeSmallInteger, alias: Total # Raised Buffers )
• TOTALTRAVELLANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Travel Lanes )
• TOTALCROSSSECTIONWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of All Cross-sections )
• TOTALPARKINGLANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Parking Lanes )
• TOTALTRAVELLANESINBOUND ( type: esriFieldTypeSmallInteger, alias: Total Inbound Travel Lanes )
• TOTALTRAVELLANESOUTBOUND ( type: esriFieldTypeSmallInteger, alias: Total Outbound Travel Lanes )
• TOTALTRAVELLANESBIDIRECTIONAL ( type: esriFieldTypeSmallInteger, alias: Total BiDirectional Travel Lanes )
• TOTALTRAVELLANESREVERSIBLE ( type: esriFieldTypeSmallInteger, alias: Total Reversible Travel Lanes )
• SUMMARYDIRECTION ( type: esriFieldTypeString, alias: General Directionality for Segment, length: 255 , Coded Values: [BD: Bi-directional] , [OB: Oneway in Outbound Direction] , [IB: Oneway in Inbound Direction] )
• BIKELANE_PARKINGLANE_ADJACENT ( type: esriFieldTypeString, alias: Parking Lane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_THROUGHLANE_ADJACENT ( type: esriFieldTypeString, alias: Throughlane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_POCKETLANE_ADJACENT ( type: esriFieldTypeString, alias: Pocket Turnlane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_CONTRAFLOW ( type: esriFieldTypeString, alias: Bikelane is Contraflow, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_CONVENTIONAL ( type: esriFieldTypeString, alias: Conventional Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_DUAL_PROTECTED ( type: esriFieldTypeString, alias: Protected Dual Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_DUAL_BUFFERED ( type: esriFieldTypeString, alias: Buffered Dual Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_PROTECTED ( type: esriFieldTypeString, alias: Protected Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_BUFFERED ( type: esriFieldTypeString, alias: Buffered Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• DOUBLEYELLOW_LINE ( type: esriFieldTypeString, alias: Double Yellow Line on Segment, length: 255 )
• SECTIONFLAGS ( type: esriFieldTypeString, alias: SectionFlags, length: 255 )
• LOC_ERROR ( type: esriFieldTypeString, alias: LOC_ERROR, length: 50 )
• MIDMEASURE ( type: esriFieldTypeDouble, alias: MIDMEASURE )
• AADT ( type: esriFieldTypeInteger, alias: AADT )
• FHWAFUNCTIONALCLASS ( type: esriFieldTypeSmallInteger, alias: FHWA Functional Class , Coded Values: [1: Interstate] , [2: Principal Arterial - Other Freeways or Expressways] , [3: Principal Arterial - Other] , ...4 more... )
• HPMSID ( type: esriFieldTypeString, alias: HPMS ID, length: 255 )
• HPMSSECTIONTYPE ( type: esriFieldTypeSmallInteger, alias: HPMS Section Type )
• ID ( type: esriFieldTypeString, alias: Overlay ID, length: 255 )
• IRI ( type: esriFieldTypeInteger, alias: IRI )
• IRI_DATE ( type: esriFieldTypeDate, alias: IRI Date, length: 8 )
• NHSCODE ( type: esriFieldTypeSmallInteger, alias: NHS Code , Coded Values: [0: Not on the NHS] , [1: Is on the NHS] , [2: Major Airport] , ...7 more... )
• OWNERSHIP ( type: esriFieldTypeString, alias: Ownership, length: 255 , Coded Values: [1: DDOT] , [5: Private] , [2: National Park Service] , ...9 more... )
• PCI_CONDCATEGORY ( type: esriFieldTypeString, alias: PCI Condition Category, length: 255 )
• PCI_LASTINSPECTED ( type: esriFieldTypeDate, alias: PCI Last Inspection Date, length: 8 )
• PCI_SCORE ( type: esriFieldTypeDouble, alias: PCI Condition Score )
• SIDEWALK_IB_PAVTYPE ( type: esriFieldTypeString, alias: Sidewalk Pavement Type (Inbound), length: 255 )
• SIDEWALK_IB_WIDTH ( type: esriFieldTypeString, alias: Sidewalk Pavement Width (Inbound), length: 255 )
• SIDEWALK_OB_PAVTYPE ( type: esriFieldTypeString, alias: Sidewalk Pavement Type (Outbound), length: 255 )
• SIDEWALK_OB_WIDTH ( type: esriFieldTypeString, alias: Sidewalk Pavement Width (Outbound), length: 255 )
• SPEEDLIMITS_IB ( type: esriFieldTypeInteger, alias: Speed Limit (Inbound) )
• SPEEDLIMITS_IB_ALT ( type: esriFieldTypeInteger, alias: Speed Limit Schools (Inbound) )
• SPEEDLIMITS_OB ( type: esriFieldTypeInteger, alias: Speed Limit (Outbound) )
• SPEEDLIMITS_OB_ALT ( type: esriFieldTypeInteger, alias: Speed Limit Schools (Outbound) )
• SUBBLOCKID ( type: esriFieldTypeString, alias: SubBlockID, length: 255 )
• BLOCKID ( type: esriFieldTypeString, alias: BlockID, length: 255 )
• BLOCKKEY ( type: esriFieldTypeString, alias: BlockKey, length: 255 )
• DCFUNCTIONALCLASS ( type: esriFieldTypeSmallInteger, alias: DC Functional Class , Coded Values: [11: Interstate] , [12: Other Freeway and Expressway] , [17: Collector] , ...3 more... )
• NHSTYPE ( type: esriFieldTypeString, alias: NHS Type, length: 255 , Coded Values: [NHS Non-Interstate: NHS Non-Interstate] , [NHS Interstate: NHS Interstate] )
• QUADRANT ( type: esriFieldTypeSmallInteger, alias: Quadrant , Coded Values: [2: NE] , [4: SW] , [0: Unknown] , ...3 more... )
• STREETNAME ( type: esriFieldTypeString, alias: Street Name, length: 255 )
• STREETTYPE ( type: esriFieldTypeString, alias: Street Type, length: 255 )
• SNOWROUTE_DPW ( type: esriFieldTypeString, alias: Snow Route DPW, length: 255 )
• SNOWZONE_DPW ( type: esriFieldTypeString, alias: Snow Zone DPW, length: 255 )
• SNOWROUTE ( type: esriFieldTypeString, alias: Snow Route, length: 255 )
• SNOWSECTION ( type: esriFieldTypeString, alias: Snow Section, length: 255 )
• SNOWZONE ( type: esriFieldTypeString, alias: Snow Zone, length: 255 )
• LEFTTURN_CURBLANE_EXCL ( type: esriFieldTypeString, alias: Exclusive Left Turn Lane Approaching Int (One way only), length: 255 )
• LEFTTURN_CURBLANE_EXCL_LEN ( type: esriFieldTypeSmallInteger, alias: Exclusive Left Turn Lane Approaching Int Length (ft) )
• RIGHTTURN_CURBLANE_EXCL ( type: esriFieldTypeString, alias: Exclusive Right Turn Lane Approaching Int (One way only), length: 255 )
• RIGHTTURN_CURBLANE_EXCL_LEN ( type: esriFieldTypeSmallInteger, alias: Exclusive Right Turn Lane Approaching Int Length (ft) )
• TOTALBIKELANES ( type: esriFieldTypeSmallInteger, alias: Bike Lane Count )
• TOTALBIKELANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Total Width of Bike Lanes )
• RPPDIRECTION ( type: esriFieldTypeString, alias: Resident Parking Permitted (Direction), length: 255 , Coded Values: [1: Outbound (with centerline geometry)] , [2: Inbound (against centerline geometry)] , [3: Bidirectional (both directions allowed)] , ...7 more... )
• RPPSIDE ( type: esriFieldTypeString, alias: Resident Parking Permitted (Side), length: 255 )
• SLOWSTREETINFO ( type: esriFieldTypeString, alias: Is Slow Street?, length: 255 )
• TOTALRAISEDBUFFERWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Buffer/Barriers )
• AADT_YEAR ( type: esriFieldTypeInteger, alias: AADT Year )
• RIGHTTURN_EXCLUSIVE ( type: esriFieldTypeString, alias: Excl Right turn Lane on Segment, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• LEFTTURN_EXCLUSIVE ( type: esriFieldTypeString, alias: Excl Left turn Lane on Segment, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BUSLANE_INBOUND ( type: esriFieldTypeString, alias: Bus Lane (Inbound), length: 255 , Coded Values: [L1: Dedicated Bus Lane in the curblane] , [L2: Dedicated Bus Lane in lane adjacent to the curblane (usually a parking lane is the curblane for these cases)] , [L3: Dedicated Bus Lane in both curblane and next lane over.] , ...4 more... )
• BUSLANE_OUTBOUND ( type: esriFieldTypeString, alias: Bus Lane (Outbound), length: 255 , Coded Values: [L1: Dedicated Bus Lane in the curblane] , [L2: Dedicated Bus Lane in lane adjacent to the curblane (usually a parking lane is the curblane for these cases)] , [L3: Dedicated Bus Lane in both curblane and next lane over.] , ...4 more... )
• FROMSTREET ( type: esriFieldTypeString, alias: From Street, length: 150 )
• TOSTREET ( type: esriFieldTypeString, alias: To Street, length: 150 )
• WARD_ID ( type: esriFieldTypeString, alias: Ward, length: 255 )
• SMD_ID ( type: esriFieldTypeString, alias: SMD, length: 255 )
• ANC_ID ( type: esriFieldTypeString, alias: ANC, length: 255 )
• NETWORK_LOGICAL_END ( type: esriFieldTypeString, alias: NETWORK_LOGICAL_END, length: 50 )
• AADT_COMBINATION ( type: esriFieldTypeInteger, alias: AADT_COMBINATION )
• AADT_COMBINATION_YEAR ( type: esriFieldTypeInteger, alias: AADT_COMBINATION_YEAR )
• AADT_SINGLE_UNIT ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT )
• AADT_SINGLE_UNIT_YEAR ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT_YEAR )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
