Name: Roadway Intersection Approach

Display Field: ROUTENAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Roads and Highways manages intersections, however they are not singular points; RH creates a series of points - one for each intersecting road at that intersection. For DDOT, it is more useful to have a single intersection point representing the intersection. Through a custom DDOT script,the series of intersection points is reduced into a single representative point.For more information please visit DDOT's wiki page at https://wiki.ddot.dc.gov/display/public/GIS/Roadway+Characteristics

Copyright Text: DC District Department of Transportation

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584340.558848506
YMin: 4692089.240566329
XMax: -8561515.62835993
YMax: 4720993.065181949
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [163, 122, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ROUTEID ( type: esriFieldTypeString, alias: Route ID for roadway, length: 255 )
• FROMMEASURE ( type: esriFieldTypeDouble, alias: From Measure (m) )
• TOMEASURE ( type: esriFieldTypeDouble, alias: To Measure (m) )
• ROUTENAME ( type: esriFieldTypeString, alias: Route Name, length: 255 )
• ROADTYPE ( type: esriFieldTypeString, alias: Road Type, length: 255 , Coded Values: [1: Street] , [2: Service Road] , [3: Ramp] , ...5 more... )
• APPROACHID ( type: esriFieldTypeString, alias: Approach ID, length: 255 )
• TOTALTRAVELLANES ( type: esriFieldTypeSmallInteger, alias: Total # Travel Lanes )
• TOTALPARKINGLANES ( type: esriFieldTypeSmallInteger, alias: Total # Parking Lanes )
• TOTALRAISEDBUFFERS ( type: esriFieldTypeSmallInteger, alias: Total # Raised Buffers )
• TOTALTRAVELLANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Travel Lanes )
• TOTALCROSSSECTIONWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of All Cross-sections )
• TOTALPARKINGLANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Parking Lanes )
• TOTALRAISEDBUFFERWIDTH ( type: esriFieldTypeSmallInteger, alias: Width of Buffer/Barriers )
• TOTALTRAVELLANESINBOUND ( type: esriFieldTypeSmallInteger, alias: Total Inbound Travel Lanes )
• TOTALTRAVELLANESOUTBOUND ( type: esriFieldTypeSmallInteger, alias: Total Outbound Travel Lanes )
• TOTALTRAVELLANESBIDIRECTIONAL ( type: esriFieldTypeSmallInteger, alias: Total BiDirectional Travel Lanes )
• TOTALTRAVELLANESREVERSIBLE ( type: esriFieldTypeSmallInteger, alias: Total Reversible Travel Lanes )
• SUMMARYDIRECTION ( type: esriFieldTypeString, alias: General Directionality for Segment, length: 255 , Coded Values: [BD: Bi-directional] , [OB: Oneway in Outbound Direction] , [IB: Oneway in Inbound Direction] )
• BIKELANE_PARKINGLANE_ADJACENT ( type: esriFieldTypeString, alias: Parking Lane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_THROUGHLANE_ADJACENT ( type: esriFieldTypeString, alias: Throughlane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_POCKETLANE_ADJACENT ( type: esriFieldTypeString, alias: Pocket Turnlane Adjacent to Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_CONTRAFLOW ( type: esriFieldTypeString, alias: Bikelane is Contraflow, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_CONVENTIONAL ( type: esriFieldTypeString, alias: Conventional Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_DUAL_PROTECTED ( type: esriFieldTypeString, alias: Protected Dual Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_DUAL_BUFFERED ( type: esriFieldTypeString, alias: Buffered Dual Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_PROTECTED ( type: esriFieldTypeString, alias: Protected Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• BIKELANE_BUFFERED ( type: esriFieldTypeString, alias: Buffered Bikelane, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• DOUBLEYELLOW_LINE ( type: esriFieldTypeString, alias: Double Yellow Line on Segment, length: 255 )
• SECTIONFLAGS ( type: esriFieldTypeString, alias: Section Flags, length: 255 )
• LOC_ERROR ( type: esriFieldTypeString, alias: LOC_ERROR, length: 50 )
• MIDMEASURE ( type: esriFieldTypeDouble, alias: Mid Measure )
• INTERSECTIONID ( type: esriFieldTypeString, alias: Intersection ID, length: 255 )
• AADT ( type: esriFieldTypeInteger, alias: AADT )
• AADT_YEAR ( type: esriFieldTypeInteger, alias: AADT Year )
• APPROACH_CARD_DIRECTION ( type: esriFieldTypeString, alias: Approach Cardinal Direction, length: 255 )
• APPROACH_INT_DIRECTION ( type: esriFieldTypeSmallInteger, alias: Approach's Geometry Direction to Intersection , Coded Values: [1: With Digitized Geometry Direction] , [2: Against Digitized Geometry Direction] )
• APPROACH_LEG_ANGLE ( type: esriFieldTypeString, alias: Approach Leg Angle, length: 255 )
• FHWAFUNCTIONALCLASS ( type: esriFieldTypeSmallInteger, alias: FHWA Functional Class , Coded Values: [1: Interstate] , [2: Principal Arterial - Other Freeways or Expressways] , [3: Principal Arterial - Other] , ...4 more... )
• HPMSSECTIONTYPE ( type: esriFieldTypeSmallInteger, alias: HPMS Section Type )
• ID ( type: esriFieldTypeString, alias: Overlay ID, length: 255 )
• IRI ( type: esriFieldTypeInteger, alias: IRI )
• IRI_DATE ( type: esriFieldTypeDate, alias: IRI Date, length: 8 )
• NHSCODE ( type: esriFieldTypeSmallInteger, alias: NHS Code , Coded Values: [0: Not on the NHS] , [1: Is on the NHS] , [2: Major Airport] , ...7 more... )
• OWNERSHIP ( type: esriFieldTypeString, alias: Ownership, length: 255 , Coded Values: [1: DDOT] , [5: Private] , [2: National Park Service] , ...9 more... )
• PCI_CONDCATEGORY ( type: esriFieldTypeString, alias: PCI Condition Category, length: 255 )
• PCI_LASTINSPECTED ( type: esriFieldTypeDate, alias: PCI Last Date Inspected, length: 8 )
• PCI_SCORE ( type: esriFieldTypeDouble, alias: PCI Condition Score )
• QUADRANT ( type: esriFieldTypeSmallInteger, alias: Quadrant , Coded Values: [2: NE] , [4: SW] , [0: Unknown] , ...3 more... )
• SIDEWALK_IB_PAVTYPE ( type: esriFieldTypeString, alias: Sidewalk Pavement Type (Inbound), length: 255 )
• SIDEWALK_IB_WIDTH ( type: esriFieldTypeString, alias: Sidewalk Pavement Width (Inbound), length: 255 )
• SIDEWALK_OB_PAVTYPE ( type: esriFieldTypeString, alias: Sidewalk Pavement Type (Inbound), length: 255 )
• SIDEWALK_OB_WIDTH ( type: esriFieldTypeString, alias: Sidewalk Pavement Width (Outbound), length: 255 )
• SPEEDLIMITS_IB ( type: esriFieldTypeInteger, alias: Speed Limit (Inbound) )
• SPEEDLIMITS_IB_ALT ( type: esriFieldTypeInteger, alias: Speed Limit School (Inbound) )
• SPEEDLIMITS_OB ( type: esriFieldTypeInteger, alias: Speed Limit (Outbound) )
• SPEEDLIMITS_OB_ALT ( type: esriFieldTypeInteger, alias: Speed Limit Schools (Outbound) )
• STREETNAME ( type: esriFieldTypeString, alias: Street Name, length: 255 )
• STREETTYPE ( type: esriFieldTypeString, alias: Street Type, length: 255 )
• SUBBLOCKID ( type: esriFieldTypeString, alias: SubblockID, length: 255 )
• BLOCKID ( type: esriFieldTypeString, alias: BlockID, length: 255 )
• BLOCKKEY ( type: esriFieldTypeString, alias: BlockKey, length: 255 )
• DCFUNCTIONALCLASS ( type: esriFieldTypeSmallInteger, alias: DC Functional Class , Coded Values: [11: Interstate] , [12: Other Freeway and Expressway] , [17: Collector] , ...3 more... )
• NHSTYPE ( type: esriFieldTypeString, alias: NHS Type, length: 255 , Coded Values: [NHS Non-Interstate: NHS Non-Interstate] , [NHS Interstate: NHS Interstate] )
• SUBBLOCKKEY ( type: esriFieldTypeString, alias: SubBlockKey, length: 255 )
• ANGLE ( type: esriFieldTypeString, alias: Approach Angle, length: 255 )
• DIRECTIONALITY ( type: esriFieldTypeString, alias: Approach Directionality, length: 255 )
• INTERSECTIONDIRECTION ( type: esriFieldTypeSmallInteger, alias: Approach Geom Dir to Intersection , Coded Values: [1: With Digitized Geometry Direction] , [2: Against Digitized Geometry Direction] )
• SNOWROUTE_DPW ( type: esriFieldTypeString, alias: Snow Route DPW, length: 255 )
• SNOWZONE_DPW ( type: esriFieldTypeString, alias: Snow Zone DPW, length: 255 )
• SNOWROUTE ( type: esriFieldTypeString, alias: Snow Route, length: 255 )
• SNOWSECTION ( type: esriFieldTypeString, alias: Snow Section, length: 255 )
• SNOWZONE ( type: esriFieldTypeString, alias: Snow Zone, length: 255 )
• LEFTTURN_CURBLANE_EXCL ( type: esriFieldTypeString, alias: Exclusive Left Turn Lane Approaching Int (Oneway only), length: 255 )
• LEFTTURN_CURBLANE_EXCL_LEN ( type: esriFieldTypeSmallInteger, alias: Length Exclusive Left Turn Lane Approaching Int (Ft) )
• RIGHTTURN_CURBLANE_EXCL ( type: esriFieldTypeString, alias: Exclusive Right Turn Lane Approaching Int, length: 255 )
• RIGHTTURN_CURBLANE_EXCL_LEN ( type: esriFieldTypeSmallInteger, alias: Length Exclusive Right Turn Lane Approaching Int (Ft) )
• TOTALBIKELANES ( type: esriFieldTypeSmallInteger, alias: Total Count of Bike Lanes )
• TOTALBIKELANEWIDTH ( type: esriFieldTypeSmallInteger, alias: Total Bike Lane Width )
• RPPDIRECTION ( type: esriFieldTypeString, alias: Resident Parking Permitted (Direction), length: 255 , Coded Values: [1: Outbound (with centerline geometry)] , [2: Inbound (against centerline geometry)] , [3: Bidirectional (both directions allowed)] , ...7 more... )
• RPPSIDE ( type: esriFieldTypeString, alias: Resident Parking Permitted (Side), length: 255 )
• SLOWSTREETINFO ( type: esriFieldTypeString, alias: Is Slow Street?, length: 255 )
• RIGHTTURN_EXCLUSIVE ( type: esriFieldTypeString, alias: Rightturn Lane on Segment, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• LEFTTURN_EXCLUSIVE ( type: esriFieldTypeString, alias: Leftturn Lane on Segment, length: 255 , Coded Values: [BD: Both Sides of Roadway] , [IB: Inbound Side of Roadway] , [OB: Outbound Side of Roadway] )
• HPMSID ( type: esriFieldTypeString, alias: HPMS Section ID, length: 255 )
• BUSLANE_OUTBOUND ( type: esriFieldTypeString, alias: Bus Lane (Outbound), length: 255 , Coded Values: [L1: Dedicated Bus Lane in the curblane] , [L2: Dedicated Bus Lane in lane adjacent to the curblane (usually a parking lane is the curblane for these cases)] , [L3: Dedicated Bus Lane in both curblane and next lane over.] , ...4 more... )
• BUSLANE_INBOUND ( type: esriFieldTypeString, alias: Bus Lane (Inbound), length: 255 , Coded Values: [L1: Dedicated Bus Lane in the curblane] , [L2: Dedicated Bus Lane in lane adjacent to the curblane (usually a parking lane is the curblane for these cases)] , [L3: Dedicated Bus Lane in both curblane and next lane over.] , ...4 more... )
• FROMSTREET ( type: esriFieldTypeString, alias: From Street, length: 150 )
• TOSTREET ( type: esriFieldTypeString, alias: To Street, length: 150 )
• WARD_ID ( type: esriFieldTypeString, alias: Ward, length: 255 )
• ANC_ID ( type: esriFieldTypeString, alias: ANC, length: 255 )
• SMD_ID ( type: esriFieldTypeString, alias: SMD, length: 255 )
• AADT_COMBINATION ( type: esriFieldTypeInteger, alias: AADT_COMBINATION )
• AADT_COMBINATION_YEAR ( type: esriFieldTypeInteger, alias: AADT_COMBINATION_YEAR )
• AADT_SINGLE_UNIT ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT )
• AADT_SINGLE_UNIT_YEAR ( type: esriFieldTypeInteger, alias: AADT_SINGLE_UNIT_YEAR )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
