Name: Roadway Block Intersection

Display Field: INTERSECTIONNAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: Roads and Highways manages intersections, however they are not singular points; RH creates a series of points - one for each intersecting road at that intersection. For DDOT, it is more useful to have a single intersection point representing the intersection. Through a custom DDOT script,the series of intersection points is reduced into a single representative point.For more information please visit DDOT's wiki page at https://wiki.ddot.dc.gov/display/public/GIS/Roadway+Characteristics

Copyright Text: DC District Department of Transportation

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584335.418736117
YMin: 4694466.530904431
XMax: -8561515.641214028
YMax: 4720993.06130656
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [0, 128, 4, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• INTERSECTIONID ( type: esriFieldTypeString, alias: INTERSECTIONID, length: 255 )
• ROUTEID ( type: esriFieldTypeString, alias: ROUTEID, length: 255 )
• MEASURE ( type: esriFieldTypeDouble, alias: MEASURE )
• INTERSECTIONNAME ( type: esriFieldTypeString, alias: INTERSECTIONNAME, length: 255 )
• GRADE ( type: esriFieldTypeSmallInteger, alias: GRADE , Coded Values: [0: At Grade] , [1: Not at Grade] , [2: Undefined] , ...8 more... )
• INTERSECTIONKEY ( type: esriFieldTypeString, alias: INTERSECTIONKEY, length: 255 )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
