Name: Alley Frontage Lines

Display Field: ALLEY_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description:

Copyright Text:

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 3000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8584254.535545932
YMin: 4695974.231580702
XMax: -8561653.264794076
YMax: 4720242.063593829
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 0, 0, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• CREATION_DT ( type: esriFieldTypeDate, alias: CREATION_DT, length: 8 )
• RECORDATION_DT ( type: esriFieldTypeDate, alias: RECORDATION_DT, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: NARRATIVE, length: 200 )
• EXPIRATION_DT ( type: esriFieldTypeDate, alias: EXPIRATION_DT, length: 8 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: SQUARE, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, length: 50 )
• RECORD_LENGTH_FT ( type: esriFieldTypeDouble, alias: RECORD_LENGTH_FT )
• RECORD_BEARING_DIR ( type: esriFieldTypeInteger, alias: RECORD_BEARING_DIR , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• RECORD_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: RECORD_BEARING_ANGLE_DD )
• RECORD_SPIRAL1_FT ( type: esriFieldTypeDouble, alias: RECORD_SPIRAL1_FT )
• RECORD_SPIRAL2_FT ( type: esriFieldTypeDouble, alias: RECORD_SPIRAL2_FT )
• RECORD_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: RECORD_ARC_LENGTH_FT )
• RECORD_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Record_Delta_Angle_DD )
• RECORD_RADIUS_FT ( type: esriFieldTypeDouble, alias: Record_Radius_FT )
• RECORD_MSL_FT ( type: esriFieldTypeDouble, alias: RECORD_MSL_FT )
• SURVEYED_LENGTH_FT ( type: esriFieldTypeDouble, alias: SURVEYED_LENGTH_FT )
• SURVEYED_BEARING_DIR ( type: esriFieldTypeInteger, alias: SURVEYED_BEARING_DIR , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• SURVEYED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: SURVEYED_BEARING_ANGLE_DD )
• SURVEYED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Surveyed_Delta_Angle_DD )
• SURVEYED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Surveyed_Radius_FT )
• COMPUTED_LENGTH_FT ( type: esriFieldTypeDouble, alias: COMPUTED_LENGTH_FT )
• COMPUTED_BEARING_DIR ( type: esriFieldTypeInteger, alias: COMPUTED_BEARING_DIR , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: COMPUTED_BEARING_ANGLE_DD )
• COMPUTED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed_Delta_Angle_DD )
• COMPUTED_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed_Arc_Length_FT )
• COMPUTED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Computed_Radius_FT )
• LINE_CLASSIFICATION ( type: esriFieldTypeInteger, alias: Line_Classification , Coded Values: [1: Street] , [2: Property] , [3: Alley] , ...5 more... )
• ALLEYLNID ( type: esriFieldTypeString, alias: ALLEYLNID, length: 50 )
• ALLEYPLYID ( type: esriFieldTypeString, alias: ALLEYPLYID, length: 50 )
• NAMED_ALLEY ( type: esriFieldTypeInteger, alias: NAMED_ALLEY , Coded Values: [1: Yes] , [0: No] )
• ALLEY_NAME ( type: esriFieldTypeString, alias: ALLEY_NAME, length: 50 )
• KILL_DT ( type: esriFieldTypeDate, alias: KILL_DT, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
