Name: Building Restriction Lines

Display Field: NARRATIVE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Lines beyond which exterior walls of buildings may not project, generally managed and recorded by the DC Department of Buildings (DOB) and the Office of the Surveyor. Land between a property line and a Building Restriction Line is considered private property set aside for public space, and its use is governed by police regulations and overseen by the DOB. Awnings, cornices, and roof overhangs—may be permitted, subject to regulations in the Public Realm Design Manual. Removal or adjustment of a building restriction line can be requested through the Surveyor's office.

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 1000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1279898.97433889
YMin: 420213.168356136
XMax: 1337341.76069981
YMax: 483941.52022987604
Spatial Reference: 102685  (2248)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 36, 135, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• RECORDATION_DT ( type: esriFieldTypeDate, alias: Recordation Date, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: Narrative, length: 200 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: Square, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: Suffix, length: 50 )
• LOT ( type: esriFieldTypeString, alias: Lot, length: 40 )
• OFFSET ( type: esriFieldTypeDouble, alias: Off Set )
• KILL_DT ( type: esriFieldTypeDate, alias: Kill Date, length: 8 )
• CREATEDBYRECORD ( type: esriFieldTypeGUID, alias: Created By Record, length: 38 )
• RETIREDBYRECORD ( type: esriFieldTypeGUID, alias: Retired By Record, length: 38 )
• DIRECTION ( type: esriFieldTypeDouble, alias: Direction )
• DISTANCE ( type: esriFieldTypeDouble, alias: Distance )
• RADIUS ( type: esriFieldTypeDouble, alias: Radius )
• ARCLENGTH ( type: esriFieldTypeDouble, alias: Arc Length )
• RADIUS2 ( type: esriFieldTypeDouble, alias: Radius2 )
• COGOTYPE ( type: esriFieldTypeInteger, alias: COGO Type , Coded Values: [1: Entered] , [2: From Geometry] , [3: Computed] )
• ISCOGOGROUND ( type: esriFieldTypeInteger, alias: Is COGO Ground , Coded Values: [0: No] , [1: Yes] )
• ROTATION ( type: esriFieldTypeDouble, alias: Rotation )
• SCALE ( type: esriFieldTypeDouble, alias: Scale )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Modified Date, length: 8 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• RECORD_BEARING_DIR ( type: esriFieldTypeInteger, alias: Record Bearing Direction , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_LENGTH_FT ( type: esriFieldTypeDouble, alias: Cmputed Length Feet )
• COMPUTED_BEARING_DIR ( type: esriFieldTypeInteger, alias: Computed Bearing Direction , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed Bearing Angle DD )
• COMPUTED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed Delta Angle DD )
• COMPUTED_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed Arc Length Feet )
• COMPUTED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Computed Radius Feet )
• RES ( type: esriFieldTypeString, alias: Reservation, length: 50 )
• PAR ( type: esriFieldTypeString, alias: Parcel, length: 50 )
• TYPE ( type: esriFieldTypeSmallInteger, alias: Type , Coded Values: [1: Alley] , [2: BuildingRestriction] , [3: HighwayPlan] )
• COGOACCURACY ( type: esriFieldTypeSmallInteger, alias: COGO Accuracy , Coded Values: [1: length represents arc or curve] , [2: Illegible dimension(s) found on source material] , [3: no dimension(s) found on source material] )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
