Name: Public Easement Lines

Display Field: NARRATIVE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Legal interests that allow government or public use of private land for specific purposes, such as utilities, access, or preservation, managed primarily through the District Department of Transportation (DDOT) and the Office of Planning. These easements are frequently established for maintenance of public infrastructure or after alley closings. Property owners must obtain written consent from the easement holder before building or subdividing, and they cannot build structures within the easement area. Under 42–1902.16 of the DC Code, valid easements exist for encroachments and support.

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 1000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1280721.46810073
YMin: 427566.130356222
XMax: 1337459.09117381
YMax: 478567.754402638
Spatial Reference: 102685  (2248)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• RECORDATION_DT ( type: esriFieldTypeDate, alias: Recordation Date, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: Narrative, length: 200 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: Square, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: Suffix, length: 50 )
• KILL_DT ( type: esriFieldTypeDate, alias: Kill Date, length: 8 )
• CREATEDBYRECORD ( type: esriFieldTypeGUID, alias: Created By Record, length: 38 )
• RETIREDBYRECORD ( type: esriFieldTypeGUID, alias: Retired By Record, length: 38 )
• DIRECTION ( type: esriFieldTypeDouble, alias: Direction )
• DISTANCE ( type: esriFieldTypeDouble, alias: Distance )
• RADIUS ( type: esriFieldTypeDouble, alias: Radius )
• ARCLENGTH ( type: esriFieldTypeDouble, alias: Arc Length )
• RADIUS2 ( type: esriFieldTypeDouble, alias: Radius2 )
• COGOTYPE ( type: esriFieldTypeInteger, alias: COGO Type , Coded Values: [1: Entered] , [2: From Geometry] , [3: Computed] )
• ISCOGOGROUND ( type: esriFieldTypeInteger, alias: Is COGO Ground , Coded Values: [0: No] , [1: Yes] )
• ROTATION ( type: esriFieldTypeDouble, alias: Rotation )
• SCALE ( type: esriFieldTypeDouble, alias: Scale )
• LOT ( type: esriFieldTypeString, alias: Lot, length: 40 )
• RES ( type: esriFieldTypeString, alias: Reservation, length: 50 )
• PAR ( type: esriFieldTypeString, alias: Parcel, length: 50 )
• TYPE ( type: esriFieldTypeSmallInteger, alias: Type , Coded Values: [1: Alley] , [2: BuildingRestriction] , [3: HighwayPlan] )
• RECORD_BEARING_DIR ( type: esriFieldTypeInteger, alias: Record Bearing Direction , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed Length Feet )
• COMPUTED_BEARING_DIR ( type: esriFieldTypeInteger, alias: Computed Bearing Direction , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed Bearing Angle Decimal Degrees )
• COMPUTED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed Delta Angle Decimal Degrees )
• COMPUTED_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed Arc Length Feet )
• COMPUTED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Computed Radius Feet )
• OFFSET ( type: esriFieldTypeDouble, alias: Offset )
• COGOACCURACY ( type: esriFieldTypeSmallInteger, alias: COGO Accuracy , Coded Values: [1: length represents arc or curve] , [2: Illegible dimension(s) found on source material] , [3: no dimension(s) found on source material] )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Modified Date, length: 8 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
