Name: Square Boundaries

Display Field: SQUARE

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Each Square is an Island, alone unto itself. There is not now nor has never been, any citywide Survey Coordinate System in D.C. Most squares are unrelated to other Squares by a “Measured” distance. They are related by Record. Street width is approximate. You cannot rely on the published official street widths to set up property lines or determine right-of-way. There is digital scan information available from DDOT regarding Right-of-Way. Some Squares are divided by streets making them muti-part and continues on the other side of the street. Since there is no citywide Survey Coordinate System, squares were placed in their approximate location. This process is known as “best fit”.

Copyright Text: District of Columbia

Default Visibility: false

MaxRecordCount: 1000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1279878.73979931
YMin: 416525.820743963
XMax: 1338041.1080544
YMax: 484118.379128128
Spatial Reference: 102685  (2248)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [0, 0, 0, 0]
Outline:
Style: esriSLSSolid
Color: [0, 0, 0, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• RECORDATION_DT ( type: esriFieldTypeDate, alias: Recordation Date, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: Narrative, length: 200 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: Square, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: Suffix, length: 50 )
• KILL_DT ( type: esriFieldTypeDate, alias: Kill Date, length: 8 )
• NAME ( type: esriFieldTypeString, alias: Name, length: 255 )
• CREATEDBYRECORD ( type: esriFieldTypeGUID, alias: Created By Record, length: 38 )
• RETIREDBYRECORD ( type: esriFieldTypeGUID, alias: Retired By Record, length: 38 )
• STATEDAREA ( type: esriFieldTypeDouble, alias: Stated Area )
• STATEDAREAUNIT ( type: esriFieldTypeInteger, alias: Stated Area Unit , Coded Values: [109401: Hectare] , [109402: Acre] , [109403: Acre US] , ...63 more... )
• CALCULATEDAREA ( type: esriFieldTypeDouble, alias: Calculated Area )
• MISCLOSERATIO ( type: esriFieldTypeDouble, alias: Misclose Ratio )
• MISCLOSEDISTANCE ( type: esriFieldTypeDouble, alias: Misclose Distance )
• ISSEED ( type: esriFieldTypeInteger, alias: Is Seed , Coded Values: [0: No] , [1: Yes] )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Modified Date, length: 8 )
• VALIDATIONSTATUS ( type: esriFieldTypeSmallInteger, alias: Validation Status , Coded Values: [0: No calculation required, no validation required, no error] , [1: No calculation required, no validation required, has error(s)] , [2: No calculation required, validation required, no error] , ...5 more... )
• ISHISTORIC ( type: esriFieldTypeInteger, alias: Is Historic , Coded Values: [0: No] , [1: Yes] )
• RECORD ( type: esriFieldTypeString, alias: Record, length: 255 )
• RETIRING_RECORD ( type: esriFieldTypeString, alias: Retiring Record, length: 255 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.AREA ( type: esriFieldTypeDouble, alias: AREA )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
