Name: Highway Plan Lines

Display Field: NARRATIVE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: If a Highway Plan line intersects a property, it acts as a building restriction line, prohibiting the creation of new record lots and limiting subdivision. These lines represent "planned" roads, not necessarily existing ones, which the District Department of Transportation (DDOT) uses for planning and managing future infrastructure. The Highway Plan originated from a mandate to expand the initial L'Enfant street grid and maintain organized development outside the original city boundaries. Highway Plan Resource Guide

Copyright Text: Department of Buildings

Default Visibility: false

MaxRecordCount: 1000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1284302.40844539
YMin: 423977.568963796
XMax: 1338182.45094757
YMax: 482709.232340127
Spatial Reference: 102685  (2248)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [166, 0, 25, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• RECORDATION_DT ( type: esriFieldTypeDate, alias: Recordation Date, length: 8 )
• NARRATIVE ( type: esriFieldTypeString, alias: Narrative, length: 200 )
• STATUS ( type: esriFieldTypeInteger, alias: Status , Coded Values: [1: Current] , [2: Dead] )
• SQUARE ( type: esriFieldTypeString, alias: Square, length: 50 )
• SUFFIX ( type: esriFieldTypeString, alias: Suffix, length: 50 )
• KILL_DT ( type: esriFieldTypeDate, alias: Kill Date, length: 8 )
• RES ( type: esriFieldTypeString, alias: Reservation, length: 50 )
• PAR ( type: esriFieldTypeString, alias: Parcel, length: 50 )
• LOT ( type: esriFieldTypeString, alias: Lot, length: 40 )
• CREATEDBYRECORD ( type: esriFieldTypeGUID, alias: Created By Record, length: 38 )
• RETIREDBYRECORD ( type: esriFieldTypeGUID, alias: Retired By Record, length: 38 )
• DIRECTION ( type: esriFieldTypeDouble, alias: Direction )
• DISTANCE ( type: esriFieldTypeDouble, alias: Distance )
• RADIUS ( type: esriFieldTypeDouble, alias: Radius )
• ARCLENGTH ( type: esriFieldTypeDouble, alias: Arc Length )
• RADIUS2 ( type: esriFieldTypeDouble, alias: Radius2 )
• COGOTYPE ( type: esriFieldTypeInteger, alias: COGO Type , Coded Values: [1: Entered] , [2: From Geometry] , [3: Computed] )
• ISCOGOGROUND ( type: esriFieldTypeInteger, alias: Is COGO Ground , Coded Values: [0: No] , [1: Yes] )
• ROTATION ( type: esriFieldTypeDouble, alias: Rotation )
• SCALE ( type: esriFieldTypeDouble, alias: Scale )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Modified Date, length: 8 )
• RECORD_BEARING_DIR ( type: esriFieldTypeInteger, alias: Record Bearing Direction , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed Length Feet )
• COMPUTED_BEARING_DIR ( type: esriFieldTypeInteger, alias: Computed Bearing Direction , Coded Values: [1: NE] , [2: NW] , [3: SE] , ...1 more... )
• COMPUTED_BEARING_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed Bearing Angle Decimal Degress )
• COMPUTED_DELTA_ANGLE_DD ( type: esriFieldTypeDouble, alias: Computed Delta Angle Decimal Degress )
• COMPUTED_ARC_LENGTH_FT ( type: esriFieldTypeDouble, alias: Computed Arc Length Feet )
• COMPUTED_RADIUS_FT ( type: esriFieldTypeDouble, alias: Computed Radius Feet )
• OFFSET ( type: esriFieldTypeDouble, alias: Offset )
• TYPE ( type: esriFieldTypeSmallInteger, alias: Type , Coded Values: [1: Alley] , [2: BuildingRestriction] , [3: HighwayPlan] )
• COGOACCURACY ( type: esriFieldTypeSmallInteger, alias: COGO Accuracy , Coded Values: [1: length represents arc or curve] , [2: Illegible dimension(s) found on source material] , [3: no dimension(s) found on source material] )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
