Name: Metro Bus Lines

Display Field: RT_D

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This line layer was created from the GTFS data feeds from the Washington D.C. Metropolitan Area Transportation Authority (WMATA) to represent the new WMATA bus transit routes for the Better Bus Network Redesign(BBNR). Lines in this layer represent individual bus routes; they were generalized from the GTFS format where lines depicted individual services. On June 29, 2025, WMATA implemented a brand new Metrobus Network – known as Better Bus. Read more about this update from BBNR info page. Each line represents the route that a specific bus follows during its daily service. The unique field, shape_id, is derived from the GTFS to identify the route, while route_id (route_shortname), direction, and variation fields use familiar letter or number designations for buses, with distinct IDs for each route. This layer was developed as part of the WMATA Better Bus Network Redesign and will be updated as necessary to reflect changes in the transit system.

Copyright Text: Washington Metropolitan Area Transit Authority

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8612547.598278344
YMin: 4677503.306359761
XMax: -8539946.24463846
YMax: 4744071.106990795
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 38, 115, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: [USERSTRIN1]
Use Coded Values: true
Symbol:
Color: [0, 38, 115, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Verdana
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 50000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• DESCRIPTION ( type: esriFieldTypeString, alias: Description, length: 255 )
• RT_D ( type: esriFieldTypeString, alias: Route Description, length: 6 )
• ROUTE ( type: esriFieldTypeString, alias: Route, length: 5 )
• DIRECTION ( type: esriFieldTypeString, alias: Direction, length: 2 )
• TYPE ( type: esriFieldTypeString, alias: Type, length: 1 )
• ORIGIN ( type: esriFieldTypeString, alias: Origin, length: 255 )
• DESTINATION ( type: esriFieldTypeString, alias: Destination, length: 255 )
• EGIS_ID ( type: esriFieldTypeInteger, alias: EGIS Identifier )
• STATE ( type: esriFieldTypeString, alias: State, length: 4 )
• STR_DATE ( type: esriFieldTypeDate, alias: Start Date, length: 8 )
• END_DATE ( type: esriFieldTypeDate, alias: End Date, length: 8 )
• SNOW_ROUTE ( type: esriFieldTypeString, alias: Snow Route, length: 1 )
• GEOMETRYSOURCE ( type: esriFieldTypeString, alias: Geometry Source, length: 50 )
• SE_ANNO_CAD_DATA ( type: esriFieldTypeBlob, alias: SE_ANNO_CAD_DATA )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• SHAPE_ID ( type: esriFieldTypeString, alias: SHAPE_ID, length: 10 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
