Name: Floodplains - Levee

Display Field: DFIRM_ID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Levee data contains information about levees shown on the FIRMs that are accredited and known to be protecting against the 1% annual-chance flood, as well as levees that are provisionally accredited, and non-accredited. The purpose of this table is to document the accreditation status of levees, as well as associated information necessary to be shown on the FIRM. The spatial entities representing levees are lines, drawn at the centerline of levees, floodwalls and levee closure structures

Copyright Text: Federal Emergency Management Agency

Default Visibility: false

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8582482.324101428
YMin: 4699480.955770569
XMax: -8571272.974798867
YMax: 4712488.37820453
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 77, 168, 255]
Width: 3
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• DFIRM_ID ( type: esriFieldTypeString, alias: Digital Flood Insurance Rate Map Identifier, length: 6 )
• VERSION_ID ( type: esriFieldTypeString, alias: Version Identifier, length: 11 )
• LEVEE_ID ( type: esriFieldTypeString, alias: Levee Identifier, length: 32 )
• FC_SYS_ID ( type: esriFieldTypeString, alias: National Levee Database (NLD) System ID (FC_SYSTEM), length: 32 )
• LEVEE_NM ( type: esriFieldTypeString, alias: Levee Name, length: 100 )
• LEVEE_TYP ( type: esriFieldTypeString, alias: Describes the type of protecting structure, length: 24 )
• WTR_NM ( type: esriFieldTypeString, alias: Surface Water Feature Name, length: 100 )
• BANK_LOC ( type: esriFieldTypeString, alias: Bank Location of Levee, length: 100 )
• USACE_LEV ( type: esriFieldTypeString, alias: U.S. Army Corps of Engineers (USACE) Levee, length: 1 )
• PL84_99TF ( type: esriFieldTypeString, alias: Levee is covered under PL84-99, length: 1 )
• CONST_DATE ( type: esriFieldTypeDate, alias: Construction Date, length: 8 )
• DGN_FREQ ( type: esriFieldTypeString, alias: Design Frequency, length: 50 )
• FREEBOARD ( type: esriFieldTypeDouble, alias: Freeboard Value )
• LEVEE_STAT ( type: esriFieldTypeString, alias: Levee Status, length: 24 )
• PAL_DATE ( type: esriFieldTypeDate, alias: Provisionally Accredited Levee Date, length: 8 )
• OWNER ( type: esriFieldTypeString, alias: Levee Owner, length: 100 )
• LEN_UNIT ( type: esriFieldTypeString, alias: This unit indicates the measurement system used for the freeboard elevations, length: 16 )
• SOURCE_CIT ( type: esriFieldTypeString, alias: Source Citation, length: 21 )
• GFID ( type: esriFieldTypeString, alias: GFID, length: 36 )
• SE_ANNO_CAD_DATA ( type: esriFieldTypeBlob, alias: SE_ANNO_CAD_DATA )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• CREATED_USER ( type: esriFieldTypeString, alias: CREATED_USER, length: 255 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: CREATED_DATE, length: 8 )
• LAST_EDITED_USER ( type: esriFieldTypeString, alias: LAST_EDITED_USER, length: 255 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: LAST_EDITED_DATE, length: 8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: Shape )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
