Name: Tile Index 1:1200 Scale

Display Field: TILE_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: 1:1200 Scale Tile Index. The dataset contains polygons used to partition the DC area into delivery units for planimetric mapping projects.Boundary geometries were updated for 2017 orthophoto capture. Adjusted the corners of the 11 tiles slightly outward to have all of them be evenly divisible by the GSD, the adjustment was only a few centimeters, an example is 2920 which was 800x800.901m (10000x10011.26 pixels) and adjusted to 800x800.96m (10000x10012 pixels). METADATA CONTENT IS IN PROCESS OF VALIDATION AND SUBJECT TO CHANGE.

Copyright Text: D.C. Office of the Chief of Technology Officer (OCTO)

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -8585223.584749637
YMin: 4690991.117356594
XMax: -8560548.794110699
YMax: 4721922.752452987
Spatial Reference: 102100  (3857)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [0, 0, 0, 0]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• TILE_NAME ( type: esriFieldTypeString, alias: Tile Name, length: 32 )
• DEL_AREA ( type: esriFieldTypeSmallInteger, alias: Deleted Area )
• DOWNTOWN ( type: esriFieldTypeString, alias: Downtown, length: 1 )
• PILOT ( type: esriFieldTypeString, alias: Pilot, length: 1 )
• PRODUCTION ( type: esriFieldTypeString, alias: Production, length: 50 )
• F2015_BLOCK ( type: esriFieldTypeSmallInteger, alias: Block 2015 )
• URL ( type: esriFieldTypeString, alias: URL, length: 254 )
• METADATA ( type: esriFieldTypeString, alias: Metadata, length: 150 )
• AREA ( type: esriFieldTypeDouble, alias: DCGIS.Tile1200Ply.AREA )
• BY8 ( type: esriFieldTypeDouble, alias: BY8 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
